Oct 09, 2020 Defining a new LaTeX command in a R Markdown document is also quite straight forward. Define the command as you would in LaTeX. Put it below the YAML header at the beginning of your R Markdown. Upmath helps writing math texts for the web. It converts Markdown syntax to HTML, and LaTeX equations to SVG images. The good news is that the fantastic new markdown LaTeX package allos you to write markdown syntax in your LaTeX documents (i.e. Simpler inputs) and still get beautifully typeset PDFs! All you need to do is load the markdown package in your document, and enclose your Markdown material within a markdown environment. Latexengine Engine to render latex, 'pdflatex', 'xelatex', or 'lualatex' X X libdir Directory of dependency files to use (Bootstrap, MathJax, etc.) X X X mathjax Set to local or a URL to use a local/URL version of MathJax to render X X X mdextensions Markdown extensions to add to default definition or R Markdown X X X X X X X X X X. This book showcases short, practical examples of lesser-known tips and tricks to helps users get the most out of these tools. After reading this book, you will understand how R Markdown documents are transformed from plain text and how you may customize nearly every step of this processing. For example, you will learn how to dynamically create content from R code, reference code in other.
Paragraph Breaks and Forced Line Breaks
To insert a break between paragraphs, include a single completely blank line.
To force a line break, put two blank
spaces at the end of a line.
Headers
The character #
at the beginning of a line means that the rest of the line is interpreted as a section header. The number of #
s at the beginning of the line indicates whether it is treated as a section, sub-section, sub-sub-section, etc. of the document. For instance, Basic Formatting in R Markdown
above is preceded by a single #
, but Headers
at the start of this paragraph was preceded by ###
. Do not interrupt these headers by line-breaks.
Italics, Boldface
Text to be italicized goes inside a single set of underscores or asterisks. Text to be boldfaced goes inside a double set of underscores or asterisks.
Quotations
Set-off quoted paragraphs are indicated by an initial >
:
In fact, all epistemological value of the theory of probability is based on this: that large-scale random phenomena in their collective action create strict, nonrandom regularity. [Gnedenko and Kolmogorov, Limit Distributions for Sums of Independent Random Variables, p. 1]
Computer Type
Text to be printed in a fixed-width font, without further interpretation, goes in paired left-single-quotes, a.k.a. “back-ticks”, without line breaks in your typing. (Thus R
vs. R.) If you want to display multiple lines like this, start them with three back ticks in a row on a line by themselves, and end them the same way:
Bullet Lists
- This is a list marked where items are marked with bullet points.
- Each item in the list should start with a
*
(asterisk) character, or a single dash (-
). - Each item should also be on a new line.
- Indent lines and begin them with
+
for sub-bullets. - Sub-sub-bullet aren’t really a thing in R Markdown.
- Indent lines and begin them with
Numbered lists
- Lines which begin with a numeral (0–9), followed by a period, will usually be interpreted as items in a numbered list.
- R Markdown handles the numbering in what it renders automatically.
- This can be handy when you lose count or don’t update the numbers yourself when editing. (Look carefully at the .Rmd file for this item.)
- Sub-lists of numbered lists, with letters for sub-items, are a thing.
- They are however a fragile thing, which you’d better not push too hard.
Title, Author, Date, Output Format, Table of Contents
You can specify things like title, author and date in the header of your R Markdown file. This goes at the very beginning of the file, preceded and followed by lines containing three dashes. Thus the beginning of this file looks like so:
You can also use the header to tell R Markdown whether you want it to render to HTML (the default), PDF, or something else. To have this turned into PDF, for instance, I’d write
Adding a table of contents is done as an option to the output type.
- To create PDF, a program called
LaTeX
(see below) has to be installed on your computer.LaTeX
is already installed on RStudio Cloud. - Other output formats may be available. See
help(render)
in thermarkdown
package. - There are many, many other formatting options which can be given in the header; see the main R Markdown help files online.
- Understand what RMarkdown is and why you should use it
- Learn how to construct an RMarkdown file
- Export an RMarkdown file into many file formats
R Markdown allows you to create documents that serve as a neat record of your analysis. In the world of reproducible research, we want other researchers to easily understand what we did in our analysis, otherwise nobody can be certain that you analysed your data properly. You might choose to create an RMarkdown document as an appendix to a paper or project assignment that you are doing, upload it to an online repository such as Github, or simply to keep as a personal record so you can quickly look back at your code and see what you did. RMarkdown presents your code alongside its output (graphs, tables, etc.) with conventional text to explain it, a bit like a notebook.
RMarkdown makes use of Markdown syntax. Markdown is a very simple ‘markup’ language which provides methods for creating documents with headers, images, links etc. from plain text files, while keeping the original plain text file easy to read. You can convert Markdown documents to many other file types like .html
or .pdf
to display the headers, images etc..
When you create an RMarkdown file (.Rmd), you use conventional Markdown syntax alongside chunks of code written in R (or other programming languages!). When you knit the RMarkdown file, the Markdown formatting and the R code are evaluated, and an output file (HTML, PDF, etc) is produced.
To see what RMarkdown is capable of, have a look at this undergraduate dissertation, which gives a concise log of their statistical analysis, or the completed demo RMarkdown file for this tutorial.
All the resources for this tutorial, including some helpful cheatsheets can be downloaded from this repository. Download by clicking on Code -> Download ZIP, then unzipping the archive in a folder you will use for this tutorial.
Read through this tutorial and use the information you learn along the way to convert the tutorial R script (RMarkdown_Tutorial.R
), which you can find in the repo, into a well commented, logically structured R Markdown (.Rmd
) document. Afterwards, there are some challenge scripts that you can convert to .Rmd
documents. If you want, you could also try converting one of your own R scripts.
Haven’t used R or RStudio before? No worries! Check out our Intro to R and RStudio tutorial, then come back here to master RMarkdown!
To get RMarkdown working in RStudio, the first thing you need is the rmarkdown
package, which you can get from CRAN by running the following commands in R or RStudio:
To create a new RMarkdown file (.Rmd
), select File -> New File -> R Markdown...
_ in RStudio
, then choose the file type you want to create. For now we will focus on a .html
Document
, which can be easily converted to other file types later.
The newly created .Rmd
file comes with basic instructions, but we want to create our own RMarkdown script, so go ahead and delete everything in the example file.
Now save the .Rmd
file to the repository you downloaded earlier from Github.
Now open the RMarkdown_Tutorial.R
practice script from the repository you downloaded earlier in another tab in RStudio
and use the instructions below to help you convert this script into a coherent RMarkdown document, bit by bit.
If you have any of your own R
scripts that you would like to make into an R Markdown document, you can also use those!
At the top of any RMarkdown script is a YAML
header section enclosed by ---
. By default this includes a title, author, date and the file type you want to output to. Many other options are available for different functions and formatting, see here for .html
options and here for .pdf
options. Rules in the header section will alter the whole document. Have a flick through quickly to familiarise yourself with the sorts of things you can alter by adding an option to the YAML
header.
Insert something like this at the top of your new .Rmd
script:
By default, the title
, author
, date
and output
format are printed at the top of your .html
document. This is the minimum you should put in your header section.
Now that we have our first piece of content, we can test the .Rmd
file by compiling it to .html
. To compile your .Rmd
file into a .html
document, you should press the Knit
button in the taskbar:
By default, RStudio opens a separate preview window to display the output of your .Rmd file. If you want the output to be displayed in the Viewer
window in RStudio
(the same window where you would see plotted figures / packages / file paths), select “View in Pane” from the drop down menu that appears when you click on the Knit
button in the taskbar, or in the Settings gear icon
drop down menu next to the Knit
button.
A preview appears, and a .html
file is also saved to the same folder where you saved your .Rmd
file.
You can use regular markdown rules in your R Markdown document. Once you knit your document, the output will display text formatted according to the following simple rules.
Formatting Text
Here are a few common formatting commands:
*Italic*
Italic
**Bold**
Bold
This is `code` in text
This is code
in text
# Header 1
## Header 2
Header 2
Note that when a #
symbol is placed inside a code chunk it acts as a normal R comment, but when placed in text it controls the header size.
* Unordered list item
1. Ordered list item
- Ordered list item
[Link](https://www.google.com)
$A = pi times r^{2}$
The $
symbols tells R markdown to use LaTeX equation syntax.
To practice this, try writing some formatted text in your .Rmd
document and producing a .html
page using the “Knit” button.
Below the YAML
header is the space where you will write your code, accompanying explanation and any outputs. Code that is included in your .Rmd
document should be enclosed by three backwards apostrophes ```
(grave accents!). These are known as code chunks and look like this:
You can quickly insert a code chunk in RStudio using a button in the toolbar:
Inside the curly brackets is a space where you can assign rules for that code chunk. The code chunk above says that the code is R code. We’ll get onto some other curly brace rules later.
Have a go at grabbing some code from the example R script and inserting it into a code chunk in your .Rmd
document.
You can run an individual chunk of code at any time by clicking on the small green arrow:
The output of the code will appear just beneath the code chunk.
More on Code Chunks
It’s important to remember when you are creating an RMarkdown file that if you want to run code that refers to an object, for example:
you must include instructions showing what dataframe
is, just like in a normal R script. For example:
Or if you are loading a dataframe from a .csv
file, you must include the code in the .Rmd
:
Similarly, if you are using any packages in your analysis, you will have to load them in the .Rmd
file using library()
as in a normal R
script.
Hiding code chunks
If you don’t want the code of a particular code chunk to appear in the final document, but still want to show the output (e.g. a plot), then you can include echo = FALSE
in the code chunk instructions.
Similarly, you might want to create an object, but not include both the code and the output in the final .html
file. To do this you can use, include = FALSE
. Be aware though, when making reproducible research it’s often not a good idea to completely hide some part of your analysis:
In some cases, when you load packages into RStudio, various warning messages such as “Warning: package ‘dplyr’ was built under R version 3.4.4” might appear. If you do not want these warning messages to appear, you can use warning = FALSE
.
REMEMBER: R Markdown doesn’t pay attention to anything you have loaded in other R scripts, you MUST load all objects and packages in the R Markdown script.
More Code Chunk Instructions
Rule | Example (default) | Function |
---|---|---|
eval | eval=TRUE | Is the code run and the results included in the output? |
include | include=TRUE | Are the code and the results included in the output? |
echo | echo=TRUE | Is the code displayed alongside the results? |
warning | warning=TRUE | Are warning messages displayed? |
error | error=FALSE | Are error messages displayed? |
message | message=TRUE | Are messages displayed? |
tidy | tidy=FALSE | Is the code reformatted to make it look “tidy”? |
results | results='markup' | How are results treated? 'hide' = no results 'asis' = results without formatting 'hold' = results only compiled at end of chunk (use if many commands act on one object) |
cache | cache=FALSE | Are the results cached for future renders? |
comment | comment='##' | What character are comments prefaced with? |
fig.width, fig.height | fig.width=7 | What width/height (in inches) are the plots? |
fig.align | fig.align='left' | 'left' 'right' 'center' |
Inserting Figures
Inserting a graph into RMarkdown is easy, the more energy-demanding aspect might be adjusting the formatting.
By default, RMarkdown will place graphs by maximising their height, while keeping them within the margins of the page and maintaining aspect ratio. If you have a particularly tall figure, this can mean a really huge graph. In the following example we modify the dimensions of the figure we created above. To manually set the figure dimensions, you can insert an instruction into the curly braces:
Inserting Tables
Standard R Markdown
While R Markdown can print the contents of a data frame easily by enclosing the name of the data frame in a code chunk:
this can look a bit messy, especially with data frames with a lot of columns. Including a formal table requires more effort.
kable() function from knitr package
The most aesthetically pleasing and simple table formatting function I have found is kable()
in the knitr
package. The first argument tells kable to make a table out of the object dataframe
and that numbers should have two significant figures. Remember to load the knitr
package in your .Rmd
file as well.
pander function from pander package
If you want a bit more control over the content of your table you can use pander()
in the pander
package. Imagine I want the 3rd column to appear in italics:
Find more info on pander here.
Manually creating tables using markdown syntax
You can also manually create small tables using markdown syntax. This should be put outside of any code chunks.
For example:
will create something that looks like this:
Plant | Temp. | Growth |
---|---|---|
A | 20 | 0.65 |
B | 20 | 0.95 |
C | 20 | 0.15 |
The :-----:
tells markdown that the line above should be treated as a header and the lines below should be treated as the body of the table. Text alignment of the columns is set by the position of :
:
Syntax | Alignment |
---|---|
`:----:` | Centre |
`:-----` | Left |
`-----:` | Right |
`------` | Auto |
Creating tables from model outputs
Using tidy()
from the package broom
, we are able to create tables of our model outputs, and insert these tables into our markdown file. The example below shows a simple example linear model, where the summary output table can be saved as a new R object and then added into the markdown file.
By using warning=FALSE
as an argument, any warnings produced will be outputted in the console when knitting but will not appear in the produced document.
Latex Table In R Markdown
Creating .pdf
documents for printing in A4 requires a bit more fiddling around. RStudio uses another document compiling system called LaTeX to make .pdf
documents.
The easiest way to use LaTeX is to install the TinyTex distribution from within RStudio. First, restart your R session (Session -> Restart R), then run these line in the console:
Becoming familiar with LaTeX will give you a lot more options to make your R Markdown .pdf
look pretty, as LaTeX commands are mostly compatible with R Markdown, though some googling is often required.
To compile a .pdf
instead of a .html
document, change output:
from html_document
to pdf_document
, or use the dropdown menu from the “Knit” button:
Common problems when compiling a .pdf
- Text is running off the page
Add a global_options
argument at the start of your .Rmd
file:
This code chunk won’t be displayed in the final document due to the include = FALSE
call and should be placed immediately after the YAML header to affect everything below that.
Latex R Markdown Reference
tidy.opts = list(width.cutoff = 60)
defines the margin cutoff point and wraps text to the next line. Play with the value to get it right.
- I lose my syntax highlighting
Use the xelatex
engine to compile your .pdf
:
By default, R markdown uses the base LaTeX engine to compile pdfs, but this may limit certain options when it comes to formatting. There are lots of other engines to play around with as well.
- My page margins are too big/small
Add a geometry
argument to the YAML header
geometry
is a LaTeX command.
- My plot/table/code is split over two pages
Add a page break before the dodgy element:
- I want to change the font
Add a font argument to your header section
mainfont
is a LaTeX command.
Have a go yourself
At this point, if you haven’t been following through already, have a go at converting the tutorial R script (RMarkdown_Tutorial.R
) into a .Rmd
document using the information above as a guide.
Remember that a good R markdown document should provide a reproducible log of your code, properly commented, with subtitles, comments and code relevant output so the reader knows what is going on.
RMarkdown outputs to a non-interactive file format like .html
or .pdf
. When presenting your code, this means you have to make a choice, do you want interactive but messy looking code (.Rmd
) or non-interactive but neat looking code (.html
, .pdf
)? R notebooks provide a file format that combines the interactivity of a .Rmd
file with the attractiveness of .html
output.
R notebooks output to the imaginatively named .nb.html
format. .nb.html
files can be loaded into a web browser to see the output, or loaded into a code editor like RStudio to see the code. You are able to interactively select which code chunks to hide or show code chunks.
Notebooks use the same syntax as .Rmd
files so it is easy to copy and paste the script from a .Rmd
into a Notebook. To create a new R Notebook file, select File -> New File -> R Notebook
. Create a notebook from your newly created .Rmd
file by copying and pasting the script. If you choose to copy and paste the script, make sure that under your YAML header, output: html_notebook instead of output: html_document.
Alternatively, to turn any existing .Rmd
file into an R
notebook, add html_notebook: default
under the output:
argument in the YAML header. If you have more than one output document type, the “Knit” button will only produce the first type. You can use the dropdown menu form the Knit button to produce one of the other types.
To output to .nb.html
, first make sure all your code chunks have been run:
then click Preview:
Notice that with R Notebooks you can still output to .html
or .pdf
, the same as a .Rmd
file.
R notebooks have only been around for about a couple of years so they’re not perfect yet, but may replace R markdown in the future for many applications.
Difference between RMarkdown and RNotebooks
R Markdown documents are ‘knitted’, while R Notebooks are ‘previewed’.
Latex R Markdown
Although the notebook preview looks similar to the knitted markdown document, the notebook preview does not execute any code chunks, but only shows you a rendered copy of the Markdown output of your document along with the most recent chunk output. The preview is also generated automatically whenever the notebook is saved. This would be especially useful if we have the preview showing in the Viewer window next to the console. This means that in R Notebooks, we are able to visually assess the output as we develop the document without having to knit the whole document again.
For example, with the following code chunk example (from the RMarkdown_Tutorial.R
practice script), we are creating a table of species richness for each taxonomic group.
To bring up the table output, we can add richness
, pander(richness)
, kable(richness)
to the end of that code chunk. If we had initially forgotten to add in either one of those functions, the table would not have been produced in both the knitted markdown document and the notebook preview. Imagine that we are now editing the R Markdown document / R Notebook document to include this function to bring up the table in the outputted document.
For RMarkdown: we would type in pander(richness)
, run that specific code chunk, and then have to click the Knit button in the taskbar to knit the whole document again.
For R Notebooks, we type in pander(richness)
, run that specific code chunk, and save the document, and the preview in the Viewer window would be updated on its own - there is no need to click the Preview button in the taskbar and run the code for the whole document.
Latex R Markdown Html
Note: R Markdown Notebooks are only available in RStudio 1.0 or higher.
Bonus task!
Either in a small group or on your own, convert one of the three demo R scripts into a well commented and easy to follow R Markdown document, or R Markdown Notebook. The files (RMarkdown_Demo_1.R
, RMarkdown_Demo_2.R
, RMarkdown_Demo_3.R
) can be found in the repo you downloaded earlier.
- You are familiar with the
Markdown
syntax and code chunk rules. - You can include figures and tables in your
Markdown
reports. - You can create RMarkdown files and export them to
pdf
orhtml
files.
Doing this tutorial as part of our Data Science for Ecologists and Environmental Scientists online course?
This tutorial is part of the Stats from Scratch stream from our online course. Go to the stream page to find out about the other tutorials part of this stream!
Latex R Markdown Example
If you have already signed up for our course and you are ready to take the quiz, go to our quiz centre. Note that you need to sign up first before you can take the quiz. If you haven't heard about the course before and want to learn more about it, check out the course page.
